Materials
Case
High purity zinc alloy.
Backset
60mm.
Latch
Stainless steel 18mm projection.
Door Thickness
30 to 45mm.
Packers
3mm thick packer plates are available, these packers are installed under lock body to align lock body with face of jamb.
Cylinders
- 5 pin tumbler mechanism outside
- Brass cylinder and brass barrel
Keying
Standard Keying
- Supplied individually keyed with two keys per lock
- 78,000 key combinations
- Key blank KB2015P
Restricted Special Keying
Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.
Lockwood Keying Platforms - more information
Finish
Dimensions | Knob
002-1K1 with Open In Strike – Single Pack
Suitable for INWARD opening timber framed doors.
002-3K1 with Metal Frame Strike – Single Pack
Suitable for INWARD opening metal framed doors.
002-4K1 with Open Out Strike – Single Pack
Suitable for OUTWARD opening timber framed doors.
Dimensions | Lever
002-1L1 with Open In Strike – Single Pack
Suitable for INWARD opening timber framed doors.
002-3L1 with Metal Frame Strike – Single Pack
Suitable for INWARD opening metal framed doors.
002-4L1 with Open Out Strike – Single Pack
Suitable for OUTWARD opening timber framed doors.
